Cigar Galaxy – Messier 82

  • by

The Cigar Galaxy, also known as Messier 82 (M82), is a famous nearby starburst galaxy located in the constellation Ursa Major.

M82 appears edge-on when seen from Earth. It has five times the luminosity of the Milky Way and lies at an approximate distance of 11.5 million light years. The galaxy’s designation in the New General Catalogue is NGC 3034. The galaxy was a site of a type Ia supernova in January 2014.

messier 82,m82

Cigar Galaxy (M82) – In M82, young stars are crammed into tiny but massive star clusters. These, in turn, congregate by the dozens to make the bright patches, or “starburst clumps,” in the central parts of M82. The clusters in the clumps can only be distinguished in the sharp Hubble images. Most of the pale, white objects sprinkled around the body of M82 that look like fuzzy stars are actually individual star clusters about 20 light-years across and contain up to a million stars. The rapid rate of star formation in this galaxy eventually will be self-limiting. When star formation becomes too vigorous, it will consume or destroy the material needed to make more stars. The starburst then will subside, probably in a few tens of millions of years. Located 12 million light-years away, M82 appears high in the northern spring sky in the direction of the constellation Ursa Major, the Great Bear. It is also called the “Cigar Galaxy” because of the elliptical shape produced by the oblique tilt of its starry disk relative to our line of sight. Image: NASA, ESA, and The Hubble Heritage Team (STScI/AURA)

The Cigar Galaxy is a site of intense starburst activity, believed to be triggered by its interaction with the nearby Messier 81 (Bode’s Galaxy). M82 belongs to the M81 Group of galaxies, which includes Messier 81, the irregular galaxy NGC 2366, the intermediate spiral NGC 2403, the barred spiral galaxy NGC 4236, the unbarred spiral NGC 2976, the dwarf irregular galaxy Holmberg IX, the peculiar galaxy NGC 3077, and several other galaxies located in the constellations Ursa Major, Draco, and Camelopardalis.

The galaxy M82 contains 197 young massive star clusters in its core region. The clusters were revealed in images taken by the Hubble Space Telescope in 2005. Starburst activity is particularly energetic in the galaxy’s central region, where stars are being formed 10 times faster than in our entire galaxy.

The active star forming region in the centre of M82 spans about 500 parsecs in diameter.

The Cigar Galaxy owes its name to its long, narrow shape and possibly also to the fact that it appears ashy when observed through small telescopes. The galaxy itself is bright enough to be seen even in binoculars.

The galaxy’s core contains four high surface brightness regions of clumps that correspond to confirmed sources of inrared, X-ray, and radio frequencies. They are believed to be starburst clusters. Supernovae in this region occur at a rate of one every 10 years.

In 2006, fluctuating X-ray emissions were discovered by the Chandra X-ray Observatory from a location some 600 light years away from the galaxy’s core. The source of the emissions is believed to be the first known intermediate-mass black hole with a mass approximately 200 to 5,000 times solar.

The Cigar Galaxy has a supermassive black hole at its core, one with a mass of about 30 million solar masses.

SUPERNOVA

A supernova was discovered in the Cigar Galaxy on January 21, 2014, when Dr. Steve J. Fossey and his students at University College London reported observing a new star in M82 from the University of London Obsevatory. By January 23, the supernova had reached a visual magnitude of 10.9. It was classified as “young, reddened Type Ia supernova,” and the International Astronomical Union (IAU) designated it SN 2014J.

supernova,cigar galaxy,m82

Spiral galaxy Messier 82 has long been known for its remarkable starburst activity, caused by interactions with its near neighbour Messier 81, and has been the subject of intense study for many years. On 21 January 2014, astronomers at the University of London Observatory in London, UK, pointed their telescope at the galaxy and spied something peculiar… an intensely bright spot seemed to have suddenly appeared within the galaxy [1]. This bright spot is actually a new supernova known as SN 2014J — the closest supernova to Earth in recent decades! Since its discovery, SN 2014J has been confirmed as a type Ia supernova, making it the closest of its type to Earth in over 40 years (since SN 1972E) [2]. This new NASA/ESA Hubble Space Telescope image is set against a previous mosaic of Messier 82 from 2006 (heic0604a), and shows the supernova as an intensely bright spot towards the bottom right of the frame. Type Ia supernovae are even more exciting for astronomers, as they have particular properties that we can use to probe the distant Universe. They are used as standard candles to measure distances and help us understand the scale of the cosmos. Catching such a supernova so soon after the event is very unusual; this early discovery will enable astronomers to explore its evolution in great detail, and to potentially infer the properties of its progenitor star. The image shown here was taken on 31 January 2014 with Hubble’s Wide Field Camera 3. This image is inset into a photo mosaic of the entire galaxy taken in 2006 with Hubble’s Advanced Camera for Surveys. Image: NASA, ESA, A. Goobar (Stockholm University), and Hubble Heritage

SN 2014J was one of the brightest and nearest supernova events seen in recent decades, along with SN 1993J, spotted in Messier 81 in 1993, and SN 1987A, which was even closer to us, only 168,000 light years away, in the outskirts of the Tarantula Nebula, an H II region in the Large Magellanic Cloud in Dorado constellation.

A type Ia supernova is believed to occur when too much stellar material piles on a white dwarf, an old star only about the size of Earth, but with gravitational power comparable to that of the Sun. A white dwarf is really the remnant core of a star that was once roughly the same size as the Sun, but then expelled its outer layers of gas, which formed a planetary nebula, while the core contracted into a dense ball of oxygen and carbon.

Once the amount of material accreted from the binary companion passes a critical threshold and the white dwarf reaches a mass 1.38 times that of the Sun, it can no longer support its mass against its own gravity. As a result, the star collapses and a thermonuclear event is ignited. The stellar material may come from a normal star or another white dwarf, which has already shed its outer layer.

Type Ia supernovae always occur with almost exactly the same amount of mass and reach almost the same peak brightness, which makes them excellent standard candles for measuring distances to the galaxies that host them; the fainter the supernova appears to us, the farther away it is. This is a technique used by astronomers and astrophysicists to determine the size of the universe, as well as its age and structure.

FACTS

The Cigar Galaxy is a peculiar galaxy believed to have a distorted disk. It was previously thought to be an irregular galaxy, but near-infrared images of the object taken in 2005 revealed that it has two symmetric spiral arms. The galaxy’s arms had not been spotted before because M82 is an edge-on galaxy with high disk surface brightness and an intricate network of filaments of dust in optical images.

Messier 82 was discovered by Charles Messier, who subsequently included the galaxy in his catalogue in the late 18th century.

m81,m82,bode's galaxy,interacting galaxies,messier 82

Galaxies M81 and M82, 8-inch SC-Telescope, Digital SLR. Image: Markus Schopfer

Messier 82 and Messier 81 make a striking pair when observed in small telescopes. M82 has been physically affected by the tidal forces resulting from the interaction, and starburst activity within the galaxy has increased tenfold. M81 and M82 have been interacting for about 100 or 200 million years. The visual separation between the two galaxies’ centres is approximately 130,000 light years.

The stars in the Cigar Galaxy’s disk are believed to have been formed in a burst some 500 million years ago and before the interaction with M81, there had not been any significant star forming activity within the galaxy outside the central region and halo. Before the encounter with Bode’s Galaxy, M82 was likely a low surface brightness object.

A radio source was detected in Messier 82 in April 2010, when astronomers at the Jodrell Bank Observatory reported finding an unknown object that started emitting radio waves that did not look like anything they had previously seen. The object has been theorized to be a micro quasar, but none of the theories are entirely backed up by the observed data.

Cigar Galaxy – Messier 82 (M82)
Constellation: Ursa Major
Distance: 11.5 million light years
Visual magnitude: 8.41
Apparent dimensions: 11′.2 x 4′.3
Coordinates: 09h 55m 52.2s (right ascension), +69°40’47” (declination)
Redshift: 203 ± 4 km/s
Designations: Messier 82, M82, NGC 3034, UGC 5322, Arp 337, PGC 28655, 3C 231

IMAGES

m82,cigar galaxy,m82 core,starburst galaxy

This image shows the most detailed view ever of the core of Messier 82 (M 82), also known as the Cigar Galaxy. Rich with dust, young stars and glowing gas, M 82 is both unusually bright and relatively close to Earth. The starburst galaxy is located around 12 million light-years away in the constellation of Ursa Major (The Great Bear). This is not the first time Hubble has imaged the Cigar Galaxy. Previous images (for example heic0604) show a galaxy ablaze with stars. Yet this image looks quite unlike them, and is dominated instead by glowing gas and dust, with the stars almost invisible. Why such a difference? The new image is more detailed than previous Hubble observations – in fact, it is the most detailed image ever made of this galaxy. But the reason it looks so dramatically different is down to the choices astronomers make when designing their observations. Hubble’s cameras do not see in colour: they are sensitive to a broad range of wavelengths which they image only in greyscale. Colour pictures can be constructed by passing the light through different coloured filters and combining the resulting images, but the choice of filters makes a big difference to the end result. Using filters which allow through relatively broad bands of colours, similar to those our eyes see, results in natural-looking colours and bright stars, as starlight shines brightly across the spectrum. Using filters transparent only to the wavelengths emitted by specific chemical elements, as in this image, isolates the light from glowing gas clouds, while blocking out much of the starlight. This explains why the stars appear faint in this image, and why the dust lanes are sharply silhouetted against the brightly glowing gas clouds. The image shows the light emitted by sulphur (shown in red), visible and ultraviolet light from oxygen (shown green and blue, respectively), and light from hydrogen (cyan). The field of view is approximately 2.7 by 2.7 arcminutes. Image: ESA/Hubble & NASA

messier 82,m82

Messier 82. Composite of Chandra, HST and Spitzer images. X-ray data recorded by Chandra appears in blue; infrared light recorded by Spitzer appears in red; Hubble’s observations of hydrogen emission appear in orange, and the bluest visible light appears in yellow-green. Image: NASA/JPL-Caltech/STScI/CXC/UofA/ESA/AURA/JHU

cigar galaxy

Composite image of the active galaxy M82 from x-ray observations by Chandra X-Ray Observatory in three energy bands coded in red (lowest energy x-ray photons), green, and blue (highest energy). Image: NASA/CXC/JHU/D.Strickland

m82 infrared

This image shows M82, also known as the “Cigar galaxy,” in infrared light, as observed by NASA’s Spitzer Space Telescope back in 2005. Astronomers discovered in early 2014 that a supernova had occurred in a particularly dusty region of M82. Spitzer has since taken a series of observations of the region. In the image, light from Spitzer’s infrared channels are colored blue at 3.6 microns and green at 4.5 microns. Image: NASA/JPL-Caltech

messier 81,messier 82

The spiral galaxies Messier 81 and 82. Photo credit: GALEX Team, Caltech, NASA
